LILYGO®

T5-2.13inch E-paper

T5-2.13inch E-paper

ESP32 4MB FLASH WIFI/Bluetooth for arduino

Regular price $16.02 USD
Regular price Sale price $16.02 USD
Sale Sold out

⚠️If you need technical support, you can get a quicker response on our GitHub (the tech team will check it directly).

Instructions Before Order

If you order the wrong product or want to add another or change your shipping address, please re-edit the correct information and place a new order, then contact us to cancel the incorrect order.

If you have a tax ID or personal ID please provide as much as possible, otherwise, if your country requires this information we will block your order and contact you via email, which will slow down the shipment.

We strongly recommend choosing DHL or FedEx if your order is over $200.

Generally, except for DHL or FedEx, we will automatically split orders over $150-200 into two packages due to customs clearance, loss prevention issues, etc.

For more please check here

Shipping & Delivery

Methods & Delivery Time

  1. Standard Express: 25-30 Days
  2. EUB: 25-30 Days
  3. YunTu Express : 10-20 Days
    (Company name can't be used consignee)
  4. DHL: 10-17 Days
  5. FedEx: 10-17 Days
  6. YanWen: 20-35 Days

Please note that all delivery times are estimated for reference only.

During ship, maybe some methods of transport do not update the logistic track until the parcel reaches the destination country.

If you do not see one of the above shipping methods when checking out, it may be because your country does not support that shipping method, please select one of the available channels already listed or contact us for help.

Please make sure your address is fully filled in (including province and continent, which will affect the shipping time of your order)

For more details please check our shipping policy.

About Tax

At present, the price of the platform does not include any tax.
European customers should pay attention to the tax problem after the package reaches the local country, which needs to be borne/handled by the customer, the local policy shall prevail

[orders over 150 euros may generate tax (Amount for reference only), for orders over this amount, we will not inform the customer separately, so please pay attention to it by yourself.]

LILYGO T5 2.13 inch E-Paper is one of the T5 series of electronic ink screen versions.

The T5 series ink screen version includes 1.02, 1.54. 2.13 and other electronic ink screen versions from small to large.

This version is a 2.13-inch ink screen with 4 grayscale versions, which can display different grayscale images, not just black and white.

Specifications

 -ESP32-D0WDQ6 V3
-4MB FLASH
-USB to TTL CH9102F
-212*104 resolution SPI interface ink screen
-RST button X1
-Custom button X4
-Micro USB
-Battery connector : Jst 2pin 1.25mm
-Battery charge and discharge protection chip
-Battery powered toggle switch
-USB input power 5V@1A
-TF card socket
-3D metal antenna & IPXE interface external antenna
-M2 positioning hole X 4

develop software:

-Micropython
-For Arduino
-IDF

Application scenario:

-Electronic work card
-STEM education
-IOT device



Technology Support [Github]

If you need technical support please check the link to find more details.

T5-2.13inch E-paper

Size



Pin Diagram









View full details

Customer Reviews

Based on 1 review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
100%
(1)
D
Dries Buytaert
Poor support

Never got a response to my support questions. I have 4 PoE shields that I can’t get to work. I emailed 3 times with no response.

Hi sir,

Please don't worry, sometimes your emails may be blocked, which email address are you contacting? We will check again. Our support team will also contact you soon. Also, you can send your question to our GitHub and our team of engineers will check it directly, so you can get a reply faster.
