T-Display S3 AMOLED

T-Display S3 AMOLED

Upgraded from an LCD to an AMOLED display, better color display

Regular price $33.98 USD
Regular price Sale price $33.98 USD
Sale Sold out

⚠️If you need technical support, you can get a quicker response on our GitHub (the tech team will check it directly). Please provide your Tax/Personal ID (if available), this will expedite the shipment of your order.

Instructions Before Order

If you order the wrong product or want to add another or change your shipping address, please re-edit the correct information and place a new order, then contact us to cancel the incorrect order.

If you have a tax ID or personal ID please provide as much as possible, otherwise, if your country requires this information we will block your order and contact you via email, which will slow down the shipment.

We strongly recommend choosing DHL or FedEx if your order is over $200.

Generally, except for DHL or FedEx, we will automatically split orders over $150-200 into two packages due to customs clearance, loss prevention issues, etc.

For more please check here

Shipping & Delivery

Methods & Delivery Time

  1. Standard Express: 25-30 Days
  2. EUB: 25-30 Days
  3. YunTu Express : 10-20 Days
    (Company name can't be used consignee)
  4. DHL: 10-17 Days
  5. FedEx: 10-17 Days
  6. YanWen: 20-35 Days

Please note that all delivery times are estimated for reference only.

During ship, maybe some methods of transport do not update the logistic track until the parcel reaches the destination country.

If you do not see one of the above shipping methods when checking out, it may be because your country does not support that shipping method, please select one of the available channels already listed or contact us for help.

Please make sure your address is fully filled in (including province and continent, which will affect the shipping time of your order)

For more details please check our shipping policy.

About Tax

At present, the price of the platform does not include any tax.
European customers should pay attention to the tax problem after the package reaches the local country, which needs to be borne/handled by the customer, the local policy shall prevail

[orders over 150 euros may generate tax (Amount for reference only), for orders over this amount, we will not inform the customer separately, so please pay attention to it by yourself.]

T-Display-S3 AMOLED is a display screen module with a 1.91" diagonal screen, based on our previous S3 module, we have upgraded the screen, resolution and antenna from LCD to AMOLED and the antenna to 3D antenna.
Using SPI interface, it is compatible with any microcontroller with SPI capability. The module is equipped with a built-in battery management system, making it a convenient solution for portable applications. The compact size and low power consumption make it ideal for wearable and IoT projects.

We have received many shares from engineers who have made the S3 module into a classic game console, monitor, timer, etc. The S3 module can carry many of your ideas. Use it to bring your ideas to life.

Version Upgrade

We've upgraded the base version (no touch functionality), check out the comparison!

V1.0 V2.0

Some of the buttons have changed positions, choose the right version according to your preference.

Specifications

MCU ESP32-S3R8 Dual-core LX7 microprocessor
Wireless Connectivity 2.4 GHz Wi-Fi & Bluetooth5 (LE)
Development Arduino, PlatformIO-IDE, Micropython
Flash 16MB
PSRAM 8MB
Bat Voltage Detection IO04
Onboard functions Boot (IO00) + Reset + IO21 Button


1.91 inch RM67162 IPS AMOLED:

Resolution 240 X RGB X 536(H)
Interface QSPI
Active Area 19.8*44.22mm
Driver IC RM67162
Viewing Angle IPS Full View Angle

Sample Code For Reference [Github]

If you need technical support please check below link to find more details.

T-Display-S3 AMOLED




Size for reference

Pin Diagram

Basic Version

Touch Version

 More Details








View full details

Customer Reviews

Based on 49 reviews
80%
(39)
4%
(2)
10%
(5)
4%
(2)
2%
(1)
K
KEEBASG TIKTOK YTB
ALMOST PERFECT

the building quality is pefect as same as the display quality , the only and major probleme is the way to code it , the libs are really hard to use and i can barelly display a static image

Hi Sir,

Am sorry to hear that, if you need tech support, you can contact our support team, or open a thread on our community, Github.
Our engineers will help you directly.

A
Anonymous
50%

Only one of them is working. I guess that's on me now, because I didn't have time so I waited almost a month to try them out.
When I tried the first I didn't quite understand why it's called touch, but at least the screen worked. Then I started to upload the examples one by one from the github repo. After trying like 5 or 6, it broke completely. Even the screen is blank now. I mean, you can still monitor the board, it's stuck in a permanent loop of some error, so kinda works, but every attempt to upload any other example fails with a "write timeout" error. Then I put it under my magnifying glass and from the side I could see that one of the two flat ribbon cables, the smaller one, is loose. I thought the bigger must be the screen and the smaller is the touch, so that's why the touch didn't work from the beginning. This board is unusable now. The error flooding the serial monitor is about some variable or parameter being uninitialized in one of the lvdl modules, braking the code. It's coming at full speed, and I believe that's the reason every attempt to upload another example code fails.
The other one of the two I bought works fine, both the screen and the touch are good.
TL;DR would be a nice board, but basically I bought one for $60.

Hi, thanks a lot for your feedback, it looks like you should be having some issues with it, you can contact our support team, if you can provide some pictures or videos this would be very helpful for our engineers to look at, you can also post threads in our GitHub and community, there will be people there to help you as well.

S
Stephane Frechette
Best display out there!

Awesome device and display. A must for projects of all kind...
Exactly what I needed ;-)

A
Amir1387ah TT
Good board!

It's cute, I love it, but I wish it had a MPU5060 or ambient sensor

D
Dieter Würtenberger
works fine

As an older software developer (83 years old), I use the board to train my interested family members. I'm using firmware release v1.0.7 with arduino 2.3.3. With the correct settings, compilation and subsequent automatic flash ran straight away. After integrating it into my LAN and adding local OPENWEATHER in factory.ino, the following picture was created. Also the SDCard example is working. So everything is ok.As an older software developer (83 years old), I use the board to train my interested family members. I'm using firmware release v1.0.7 with arduino 2.3.3. With the correct settings, compilation and subsequent automatic flash ran straight away. After integrating it into my LAN and adding local OPENWEATHER in factory.ino, the following picture was created. Also the SDCard example is working. So everything is ok.
