T-Display S3 Long

T-Display S3 Long

$32.13
$32.13
Sale Sold out

Methods & Delivery Time

  1. Standard Express: 25-30 Days
  2. YunTu Express : 10-20 Days
    (Company name can't be used consignee)
  3. DHL: 10-17 Days
  4. FedEx: 10-17 Days

Please note that all delivery times are estimated for reference only.

Check More Info: Shipping Policy

We only charge the product cost and shipping cost.

1. For Standard Express Order: You may not need to deal with customs clearance, just need to pay attention to the track of the parcel, but this is not absolute, if your parcel is inspected by the customs, then you need to assist in dealing with customs clearance.

2. For DHL/ FedEx Order: You need to deal with the relevant customs clearance matters, as well as pay the tariff, the specific amount of tariff please pay attention to the policy of your country.

----------------------

The above tariffs are for reference only, please pay attention to your country's tax policy for more detailed instructions, if you need our help or have questions please feel free to contact us.

If you need extension cable, click here

Specifications

MCU ESP32-S3R8 Dual-core LX7 microprocessor
Wireless Connectivity Wi-Fi 802.11, BLE 5 + BT mesh
Programming Platform Arduino-ide, VS Code
Flash 16MB
PSRAM 8MB
Bat voltage detection IO02
Onboard functions Boot + Reset Button, Battery Switch
 3.4-inch Capacitive Touch TFT LCD (Support Touch Function):
Color depth 565, 666
Resolution 180(H)RGB x640(V)
Interface QSPI

Sample Code For Reference [Github]

If you need technical support please check below link to find more details.

T-Display-S3 Long

Pin Diagram

More

What's In The Box

Basic Version

With Shell Version



View full details

  • Who can use

    It's easier to master these development boards with a basic programming knowledge [engineers/ students/ makers, etc..]

  • Accelerated processing

    International orders please make sure your address is in English
    For Hong Kong, Macau and Taiwan orders, please note your personal ID.

  • Got a question

    Click on the bubble in the bottom right corner where some frequently asked questions are answered, or just drop us a line.

Customer Reviews

Based on 15 reviews
47%
(7)
13%
(2)
20%
(3)
20%
(3)
0%
(0)
M
Mike Morrow (c/o Rick Jason Lallave}
Less than totally useful

I got a T-DIsplay S3 Long to try out. If found it difficult to use. There is a reset button on the bottom that sticks out. If you sit the unit on that bottom edge, the reset button gets pressed because it sticks out. Yes, I could turn it over but the location of my power dictates having it the other way. You would call that upside down. I call it necessary. There is a placard plastered to the back of the unit making the battery connector essentially useless. There are closely spaced pins that don't match the standard. I have found adapters cables to mate with this that I must now order. Not terribly happy with it. I got it because of the flip clock factory app but found out that it cheats. When going from 59 seconds or minutes to 00, it first goes to 9, then flops to 0. Someone was too lazy to make a 5 to 0 flip card. Sad... I will get back to playing with it soon. Not sure what I will do with it but something will come up.

M
Morgan Yunker
Excellent board

Excellent board with some documentation issues. Seems to be a bit of confusion about this board and a version with a built-in SD card slot (which is included in the online documentation's schematic)
Great display with good viewing angles

N
Nick Gauntlett
Hardware is great, Software no longer works.

The device itself is great. It looks great, feels well built, and overall seems like a good design. But the provided software no longer works. Someone on GitHub had managed to rework the code in order to get it to load some basic demos, but I haven't gotten much further than that.

J
John Stockdale
Love these units!

I’ve been writing custom firmware for these and turning them into ntp clocks, serial consoles, and more. Highly recommend! Make sure you understand you need to customize the code yourself to have it do helpful things.

P
Pim S
Fantastic display, lacking support

The display is fantastic and perfectly fits my project. High contrast (black = black), high resolution, good colours and the bezel is perfect to fit seamlessly in a frame to give it a real professional look.

I find the software support lacking. I got it to work but needed examples from other people (Volos projects for instance) and even then the display is capable of more. Lilygo should focus more on extensive software support with clear examples and not push a lot of new hardware to the market every few months without proper documentation.
