LILYGO® TTGO T-WATCH 2020 V2 GPS IPS Open Source ESP32 WIFI Bluetooth Capacitive Touch Screen Programmable Watch Vibration Motor
T-WATCH-2020 V2 |
LILYGO T-WATCH-2020 V2 is used by replacing the MAX98357 speaker function of T-WATCH-2020 V1 with GPS and a 13pin expansion TF card holder and adding a DRV2605L tactile vibration sensor, which can be programmed to set different vibration status reminders. |
T-WATCH-2020 V1 |
LILYGO T-WATCH-2020 V1 is based on a design concept that can be programmed, can be worn, can be networked, and can be interactive. It integrates ESP32 with WIFI/Bluetooth, which is easy to program and develop and is more convenient to connect to the Internet. It uses the 2D IPS 1.54-inch watch capacitive touch screen of the OCA process, and the metal process frame of zinc alloy makes the device structure more sturdy and beautiful, suitable for wearable use. The sensitive capacitive touch screen makes human-computer interaction smoother. |
About T-WATCH-2020 |
T-WATCH-2020 has three versions now, the T-WATCH-2020 V1 version, the T-WATCH-2020 V2 version, and the T-WATCH-2020 V3 version. |
T-WATCH-2020 Difference |
T-WATCH-2020 V3 version is added a PDM Microphone base on T-WATCH-2020 V1. |
T-WATCH-2020 V2 version replaces the function of Max98357A of V1 version with GPS function and expands to TF card holder. T-WATCH-2020 V2 version replaces the V1 version Vibration Motor with DRV2605L. DRV2605L adds haptic motor control and can set various vibration modes. |

Specifications
MCU | ESP32-D0WDQ6-V3 Xtensa LX6 microprocessor |
LASH | 4MB |
PS RAM | 8MB |
Clock | 240Mhz |
Wireless | Wi-Fi: 802.11 b/g/n, Bluetooth: V4.2+ BLE |
Onboard Functions | I2C Haptic Vibration Motor Infrared IR receiving and sending, FPC interface |
1.54-inch IPS wide-angle touchscreen |
Resolution | 240x240 |
Screen Driver | ST7789 |
Equipped with sensors |
L76K GNSS | Support GPS, Beidou, GLONASS, Galileo |
BMA423 | Three-axis accelerometer running/walking/ still mode detection |
AXP202 | PMU power management chip |
Support | OCP、OVP、UVP、OTP function |
1. Size

2. Pin Diagram

3. Appearance Details

Application Scenarios: |
-IOT terminal controller |
-Voice interaction |
-Wearable devices |
-STEM education product |
-DIY creation |
-GPS positioning |

- 1 X T-WATCH-2020 V2 version(silver/Gun color)
- 1 X Micro USB 30cm cable

T-WATCH-2020 V2 (silver/Gun color)+Transparent Strap
- 1 X T-WATCH-2020 V2 (silver/Gun color)
- 1 X Transparent Strap
- 1 X Micro USB 30cm cable
