LoRa32 V1.0 Introduction
-
This product is an LoRa [SX1276 chip] Module based on ESP32 with 0.96 Inch OLED . As a LoRa remote modem, 868-915MHz frequency, high sensitivity and reliability, long transmission distance.
-
Supports for Arduino development environment perfectly, can be used for program checking and the development is easy and fast.
- It is recommended to purchase two piece for testing in order to transmit and receive data facilitatly.
Specification
| MCU | ESP32 |
| LoRa Chip | SX1276 |
| Flash | 4M |
| USB to TTL chip | CH910X |
| Antenna |
Onboard WiFi 3D antenna IPEX holder LoRa antenna |
| OLED |
0.96 Inch SSD1306 OLED 128*64 |
| Operating voltage | 3.3V to 7V |
| Operating temperature range | -40 ° C to + 90 ° C |
| Data rates | 150 Mbps @ 11n HT40, 72 Mbps @ 11n HT20, 54 Mbps @ 11g, 11 Mbps @ 11b |
| Transmit power | 19.5 dBm @ 11b, 16.5 dBm @ 11g, 15.5 dBm @ 11n Receiver sensitivity up to -98 dBm |
| Red light | power indicator |
| Blue light | IO25 programmable control |
| Support for Sniffer software protocol analysis, Station, SoftAP, and Wi-Fi Direct modes |
| UDP sustained throughput of 135 Mbps |
Technology Support [Github]
If you need technical support please check the link to find more details.
-
The 868/915MHz antenna needs to be in connection with the IPEX interface
-
Lithium battery charge and discharge circuit, when the battery is full, the blue LED will stop working.
-
When using, pay attention to “+”and "-" of the battery.
-
With IO port touch screen touch signal input, you need to add the 100nF pull-down capacitor to this pin!
-
Note: This product does not include the battery.
1. Size
2. Pin Diagram
LoRa32 V1.0 868/915Mhz Module
-
1 X LoRa32 V1.0 868/915Mhz Module
-
1 X Power cable (Jst 2pin 1.25mm)
-
1 X LoRa 868/915Mhz Antenna
-
2 X Pin
Waterproof Box [Color depends on your choice]
